4(a)(i)Heart CirculationMedium3 marks

A student investigated the structure of muscular arteries.

Figure 4.1 is a photomicrograph of a transverse section (TS) of a muscular artery and surrounding tissue.

Figure 4.1, a photomicrograph at ×120 magnification of a transverse section of a muscular artery and surrounding tissue, with a box marking the area enlarged in Figure 4.2

Figure 4.2 is a photomicrograph of part of a TS of the muscular artery as indicated in Figure 4.1.

Figure 4.2, a photomicrograph at ×750 magnification of part of the wall of the muscular artery shown in Figure 4.1, with three regions labelled: P (the innermost, folded layer next to the blood cells), Q (a thick middle layer of muscle fibres) and R (the outermost, fibrous layer)

Identify the main component of each of the regions P, Q and R shown in Figure 4.2.

Region	Response
P	Table answer rowP_Response
Q	Table answer rowQ_Response
R	Table answer rowR_Response

4(a)(ii)Heart CirculationMedium3 marks

Explain how the structure of the muscular artery shown in Figure 4.1 and Figure 4.2 is related to its function.

Answer

0 words

4(a)(iii)Heart CirculationMedium2 marks

Describe how the appearance of a TS through the aorta of a mammal differs from the appearance of the TS of the muscular artery shown in Figure 4.1.

Answer

0 words

4(b)Immune System DefencesMedium2 marks

The student did not observe any neutrophils or lymphocytes in the blood in the centre of the section shown in Figure 4.1.

Draw a neutrophil and a lymphocyte, as seen in a sample of mammalian blood that has been stained to show nuclei. Do not add any labels.

Draw with the mouse or a finger.

4(c)Gas ExchangeEasy1 mark

The student also investigated transverse sections of lung tissue. State one feature of the wall of a bronchus that is not found in the wall of an artery in lung tissue.

Answer

0 words
